Dynemech ANTI VIBRATION PRECISION METROLOGY TABLE FOR SURFCOM 480A-14 P 64

1. Granite base of size L 1100 X B 550 X T 50 mm
   2. 60 mm Tubular Structure with cross member to suit 1000 X 450 X 80 mm Granite Base
   3. Wrap Around Construction
   4. Front pivot jointed heavy duty links with extended horizontal connecting profile and vertical 45 X 45 connecting profile. At top end another horizontal 90 X 45 profile connection with needle thrust bearing supported swiveling assembly with tray to suit display unit with clamping lever at bottom (newly introduced!).
   5. 65 X 65 mm AV pads at 9 places
   6. 4 No’s DLP3 (AV disc with adjustable screws) at Ground Level
   7. 4 No’s – 3” Wheel
   8. Drawing Pouch L.H Side and front double door with handles and lock
   9. Leveling Ball, Spanner 24/27
   10. Powder Coat, structure RAL 9002, side sheets and doors – graphite gray
   11. Instrument sticker
   12. Overall dimensions: L 1120 X B 570 X H 730 (over granite base) mm
   13. Weight: kg
   14. Execution in wooden box

https://vibrationmountsindia.com/

Note-Freight charges are excluded.
