Dynemech Granite Anti Vibrating Table for Roundtest with Air Cushion , P-84-02-D

1. Granite base of size L 750 X B 600 X T 30 mm
   2. 60 mm Tubular Structure with cross member
   3. Wrap Around Construction with left angular profile
   4. 4 No’s DLP3 (AV disc with adjustable screws) at Ground Level
   5. 4 No’s – 3” Wheel
   6. Front keyboard panel for aesthetic purpose
   7. Pneumatic supported membrane air springs with 3 sensors and auto leveling within ± 0.15 mm complete with manifold and regulator, FRL unit, shut-off wall and NRV. Completely enclosed in laser cut SS side sheet.
   8. Additional printer stand to accommodate CPU console, monitor, keyboard and mouse; and pull-out tray
   9. Power Strip in Rear; controller and UPS inside structure
   10. Drawing Pouch LH Side, cable manager at rear side
   11. Front double door with handles and lock
   12.Leveling Ball, Spanner 24/27
   13. Powder Coat, structure, side sheets and doors RAL 9002
   14. Instrument sticker
   15. Overall dimensions: L 770 X B 770 X H 730 (over granite base) mm
   16. Printer stand dimensions: L 600 X B 770 X H 730 mm
   17. Weight: kg
   18. Execution in wooden box

https://vibrationmountsindia.com/

Note- Freight charges are excluded.
